SSL Series Electric Self-Propelled Scissor Lift
Battery-electric, zero-emission elevating work platforms with working heights from 6.49 M to 14 M. Engineered for stable, quiet operation in warehouses, manufacturing plants, construction, and maintenance applications across the UAE.
For the full range, see our overview of scissor lifts and aerial work platforms in the UAE.
Product Overview
The Soosung SSL Series is a comprehensive range of electric self-propelled scissor lifts designed to deliver safe, efficient, and emissions-free aerial access. Spanning six models from the compact SSL-1432 to the heavy-duty SSL-4070, the range covers platform working heights up to 14 metres, making it one of the most versatile electric scissor lift families available in the UAE.
Powered entirely by a 24V battery system with a built-in on-board charger, the SSL Series produces zero exhaust emissions and minimal noise — ideal for indoor use in warehouses, retail spaces, cold storage, and clean manufacturing environments. The hydraulic scissor mechanism provides smooth, stable elevation, while a one-hand proportional joystick enables precise simultaneous travel and positioning even at full height.
Key Features & Benefits
24V battery drive with built-in charger (10×220V, 50/60Hz). Safe for indoor use.
Standard on SSL-1932 & SSL-3370 — extends platform area without growing the footprint.
Inside curve from 1.44 m for navigating narrow warehouse aisles.
One-hand control for precise, simultaneous travel and lift at height.
Power tools directly from the platform — no trailing cables.
Engages when stationary to prevent unintended movement on inclines.
Manual descent capability in the event of power loss.
Real-time tilt monitoring with operator alert beyond safe gradient.
Designed for quick service access, reducing downtime.
Technical Specifications
| Specification | SSL-1432 | SSL-1932 | SSL-2046 | SSL-2646 | SSL-3370 | SSL-4070 |
|---|---|---|---|---|---|---|
| Height | ||||||
| Working Height (Max) | 6.49 m | 7.8 m | 8.07 m | 9.9 m | 12 m | 14 m |
| Platform Height (Max) | 4.49 m | 5.8 m | 6.07 m | 7.9 m | 10 m | 12 m |
| Platform Height (Min) | 0.9 m | 1.02 m | 1.02 m | 1.18 m | 1.65 m | 1.87 m |
| Guardrail Height | 1.1 m | 1.1 m | 1.1 m | 1.1 m | 1.1 m | 1.1 m |
| Dimensions | ||||||
| Overall Length | 1.85 m | 1.85 m | 2.39 m | 2.39 m | 3.51 m | 3.51 m |
| Overall Width | 0.84 m | 0.84 m | 1.25 m | 1.25 m | 1.73 m | 1.73 m |
| Ext. Platform Length | 0.85 m | 0.85 m | — | 0.85 m | 1.2 m | 1.2 m |
| Load Capacity | ||||||
| Main Platform | 270 kg | 227 kg | 450 kg | 390 kg | 600 kg | 300 kg |
| Ext. Platform | 113 kg | 113 kg | — | 136 kg | 159 kg | 155 kg |
| Persons (80 kg) | 1 | 1 | 2 | 2 | 3 | 3 |
| Performance | ||||||
| Travel Speed (High) | 3 km/h | 3 km/h | 2.5 km/h | 2.5 km/h | 2.8 km/h | 2.8 km/h |
| Gradeability | 20% | 20% | 20% | 20% | 20% | 20% |
| Lift / Lower Time | 20/48 s | 25/52 s | 40/54 s | 49/56 s | 60/50 s | 63/54 s |
| Power & Drive | ||||||
| Battery | 24V (4×6V 225Ah) | 24V (8×6V 225Ah) | 24V (8×6V 225Ah) | |||
| Charger | 10×220V, 50/60Hz (30A) | 10×220V, 50/60Hz (40A) | 10×220V, 50/60Hz (40A) | |||
| Tyre (Solid) | 3.00-8 | 4.00-8 / 27×10-12 | ||||
| Drive System | Hydraulic Front-Drive | DC Geared Motor Rear-Drive | ||||
| Brake | Hydraulic | |||||
| Weight (incl. battery) | 1,224 kg | 1,267 kg | 2,117 kg | 2,375 kg | 3,970 kg | 4,200 kg |
⚠ Specifications are subject to change without prior notice. Source: official Soosung SSL Series brochure.
Applications
Warehouses
Racking, lighting & HVAC maintenance in high-bay storage.
Distribution Centres
Picking and facility upkeep in fast-paced logistics hubs.
Logistics Terminals
Conveyor and loading-bay infrastructure maintenance.
Manufacturing
Access to machinery, overhead services & mezzanines.
Retail Storage
Quiet after-hours fit-out and signage installation.
Cold Storage
Zero-emission operation compliant for food-safe facilities.
Bring the load up to the worker, not the worker down to the load
Most back strain in a warehouse or workshop comes from the same place: people bending over pallets and crates at floor level, hundreds of times a shift. An electric scissor lift like the SSL fixes that quietly by raising the load to a comfortable working height, so packing, assembly and order-picking happen at waist level instead of on the floor.
It is one of those tools whose value is easy to underrate until you watch a team use one. Pair it with a packing bench or a loading dock and the awkward lifting more or less disappears, which matters as much for staff retention and injury claims as it does for speed.
Where we see it earn its keep
Assembly and sub-assembly stations, pack-and-dispatch benches, machine feeding, and dock-height matching when a trailer floor and your floor do not line up. Tell us the load weight and the height range you need and we will point you to the right capacity rather than guessing.
Interested in the Soosung SSL Series?
ARAS Developments FZE is your authorised supplier of Soosung aerial work platforms in the UAE.
Get pricing & availability.
Frequently Asked Questions
What is the Soosung SSL electric scissor lift used for?
Raising loads to a comfortable working height — packing, assembly, machine feeding and dock-level matching. It is about removing the bending and heavy lifting at floor level, not working at height like an access platform.
How much weight and height can the SSL handle?
It depends on the model; capacity and lift range vary across the range. Tell us the heaviest load and the working height you need and we will confirm the right specification.
Do you supply and deliver the Soosung SSL Electric Scissor Lift across the UAE?
Yes. ARAS Developments FZE supplies and delivers the Soosung SSL Electric Scissor Lift across all seven emirates of the UAE, with on-site service and genuine spare parts.
Is ARAS the authorised Soosung distributor in the UAE?
Yes. ARAS Developments FZE is the authorised distributor of Soosung material-handling equipment in the UAE.
Can I get pricing, a demo or the specification sheet for the Soosung SSL Electric Scissor Lift?
Yes. Contact ARAS Developments FZE for current pricing, an on-site demonstration and the full specification of the Soosung SSL Electric Scissor Lift.
